Belimo Modulating Damper Actuator

Full description:
The Belimo NM24A-SR modulating actuator is designed to operate air dampers in HVAC and building-services installations. It provides proportional control, position feedback and dependable non-spring-return operation. Its compact direct-mount design helps simplify professional installation.

Specifications—subject to model confirmation:

• Nominal voltage: AC/DC 24V
• Motor torque: 10 Nm
• Control signal: 2–10V
• Position feedback: 2–10V
• Non-spring-return operation
• Direction of rotation selectable
• Direct mounting on compatible damper shafts
• Manual override function

Belimo’s official documentation confirms these values for model NM24A-SR, including 10 Nm torque and 2–10V control/feedback. However, the model printed in the AEView advertisement is not completely legible, so verify the product label first. Belimo NM24A-SR documentation
